Produktdetails:
|
| Name: | Druck-Dichtung Kugel-Ventil | Druck: | 900Lb~2500Lb |
|---|---|---|---|
| Anwendung: | General | Struktur: | Sicherheit |
| Markieren: | CS 900Lb Schieber,Kugelventil 900Lb SS,3/4" SS-Kugelventil |
||
|
NEIN.
|
Teil-Name
|
CS zu ASTM
|
Hinsichtlich ASTM
|
SS zu ASTM
|
|
|
Art A105T
|
Art A182 F22
|
Art A182 F304
|
Art A182 F316 (L)
|
||
|
1
|
Körper
|
A105
|
A182 F22
|
A182 F304 (L)
|
A182 F316 (L)
|
|
2
|
Diskette
|
A276 420
|
A276 304
|
A276 304 (L)
|
A276 316 (L)
|
|
3
|
Stamm
|
A182 F6
|
A182 F304
|
A182 F304 (L)
|
A182 F316 (L)
|
|
4
|
Druck Seat
|
A105
|
A182 F304
|
A182 F304 (L)
|
A182 F316 (L)
|
|
5
|
Druck-Ring
|
A182 F304 L
|
A182 F316L
|
||
|
6
|
Mütze
|
A105
|
A182 F22
|
A182 F304 (L)
|
A182 F316 (L)
|
|
7
|
Pin
|
A276 420
|
A182 F304
|
||
|
8
|
P.S.Washer
|
A105
|
A182 F22
|
A182 F304 (L)
|
A182 F316 (L)
|
|
9
|
P.S.Lock-Nuss
|
A194 2H
|
A194 4
|
A194 8
|
A194 8M
|
|
10
|
Stamm-Verpackung
|
Gewölbt SS + Graphit
|
SS+PTFE
|
||
|
11
|
Drüse
|
A276 420
|
A182 F304
|
||
|
12
|
Drüsen-Flansch
|
A216 WCB
|
A351 CF8
|
||
|
13
|
Drüsen-Ringbolzen
|
A193 B7
|
A193 B16
|
A193 B8
|
A193 B8M
|
|
14
|
Überwurfmutter
|
A194 2H
|
A194 4
|
A194 8
|
A194 8M
|
|
15
|
Yoke Nut
|
A276 410
|
|||
|
16
|
Handrad
|
A197
|
|||
|
17
|
Nummernschild
|
SS
|
|||
|
18
|
H.W.Nut
|
A194 2H
|
A194 4
|
A194 8
|
A194 8M
|
|
Passendes Medium
|
W.O.G.etc
|
W.O.G.etc
|
HNO3CH3OOH usw.
|
||
|
Passende Temperatur
|
-29~425
|
-29~550
|
-29~180
|
||
|
NPS
|
1/2“
|
3/4"
|
1"
|
1-1/4“
|
1-1/2“
|
2"
|
|
|
L
|
900~1500Lb
|
140
|
140
|
140
|
178
|
178
|
216
|
|
2500Lb
|
186
|
183
|
186
|
232
|
232
|
279
|
|
|
H (OFFEN)
|
333
|
333
|
333
|
408
|
408
|
524
|
|
|
W
|
160
|
160
|
180
|
200
|
250
|
280
|
|
|
Gewichte
|
900Lb~1500Lb
|
11,2
|
10,5
|
10,1
|
21,0
|
19,6
|
40,4
|
|
2500Lb
|
12,3
|
11,6
|
10,8
|
28,0
|
26,4
|
43,8
|
|
